Loading Specifications | SYNTHETEC® E.V.A Stone Grating
The Loading applications are the first thing you should consider when looking to purchase SYNTHETEC® Stone Grating, to guarantee that you are selecting the right one.
SYNTHETEC® E.V.A Stone Grating Project Reference
Le Pont | Landscape
Project Date: MAY 2019
Clients: Vanke Property (HK) Company Limited
Location: 99 So Kwun Wat Road, Tuen Mun, New Territories
Kowloon Commerce Centre
Project Date: JUN 2019
Clients: Kai Shing Management Services Limited
Location: Tai Lin Pai Road, Kwai Hing, Hong Kong
Loading Specifications
Group 1
Pedestrian
![](https://static.wixstatic.com/media/418c0b_9468739998834f3ebf0afd339aae94a3~mv2.png/v1/fill/w_312,h_178,al_c,q_95/418c0b_9468739998834f3ebf0afd339aae94a3~mv2.webp)
- – Withstanding a 5kN test load
- – Appropriate for pedestrians
A15 Pedestrian
![](https://static.wixstatic.com/media/418c0b_902c320b02a24b32a157ce5f2bd32947~mv2.png/v1/fill/w_498,h_170,al_c,q_95/418c0b_902c320b02a24b32a157ce5f2bd32947~mv2.webp)
- Comply with BS EN 124 : 2015
- – Withstanding a 15kN test load.
- – For use in areas where pedestrians, pedal cyclists, and wheelchairs have access.
Group 2
Light Vehicle
![](https://static.wixstatic.com/media/418c0b_41815de1d54e4e578f32c8094aa6cc4f~mv2.png/v1/fill/w_342,h_201,al_c,lg_1,q_95/418c0b_41815de1d54e4e578f32c8094aa6cc4f~mv2.webp)
- – Withstanding a 60kN test load.
- – For use in pedestrian and car parks areas with occasional and slow-moving vehicular access.
B125 Light Vehicle
![](https://static.wixstatic.com/media/418c0b_193f6bee72e54bac8d80cbe3ef61b3c4~mv2.png/v1/fill/w_328,h_188,al_c,lg_1,q_95/418c0b_193f6bee72e54bac8d80cbe3ef61b3c4~mv2.webp)
- Comply with BS EN 124: 2015
- – Withstanding a 125 kN test load.
- – B125 Light vehicle is a robust choice in many cases where light vehicular, slow-moving traffic is present.
Group 3
C250 Heavy Vehicle / E.V.A
![](https://static.wixstatic.com/media/418c0b_189e4cab8aca465a92b64c6485ed2397~mv2.png/v1/fill/w_314,h_177,al_c,q_95/418c0b_189e4cab8aca465a92b64c6485ed2397~mv2.webp)
- Comply with BS EN 124: 2015
- – Withstanding a 300kN test load.
- – For use in areas where all cars, lorries, and fire trucks have access, including carriageways, hard shoulders pedestrian areas and emergency vehicular access.
D400 Heavy Vehicle
![](https://static.wixstatic.com/media/418c0b_f7c99f0fa9fe4432b598b5484a004abf~mv2.png/v1/fill/w_314,h_181,al_c,q_95/418c0b_f7c99f0fa9fe4432b598b5484a004abf~mv2.webp)
- Comply with BS EN 124 : 2015
- – Withstanding a 400kN test load.
- – For use in areas where all types of road vehicles have access, including carriageways of road, hard shoulders, and pedestrian areas.
